Chasis Model

ZZ1257M4647C

Truck Brand

SINOTRUK-HOWO

Color

Optional

Dimension(Lx W xH)(unloaded)(mm)

10500×2500×3600

Tank Volume(m3)

25m3

Tank body(thickness):5mm,material:carbon steel; sprinkling equipment both in front and in rear; special anti-corrosion treatment

Approaching angle/Departure angle(°)

16/12

Overhang(front/rear) (mm)

1500/2900

Wheel base (mm)

4600+1350

Max speed(km/h)

75

Curb weight(kg)

11360

Total Weight(kg)

25000

Engine

(Steyr technology, made in China)

Model

WD615.69,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection

Fuel type

Diesel

Power, max(kw/rpm)

336HP

Emission

EURO II

Fuel tanker capacity (L)

350

Transmission

Model

HW19710,10 forward

Brake system

Service brake

Dual circuit compressed air brake

Parking brake

spring energy, compressed air operating on rear wheels

Steering system

Model

Power steering

Front axle

HF7 disc brake

Loading weight:7000kg

Rear axle

HW1279

Loading weight:12000kg

Tyre

12.00-20   10+1spare

Electrical system

Battery

2X12V/165Ah

Alternator

28V-1500kw

Starter

7.5Kw/24V

Cab

HOWO76 standard cab, one sleeper with air-conditioner
