Hydraulic Diesel 500L Concrete Mixer

Hydraulic Diesel 500L Concrete Mixer for sale
Power: 15/18hp
Weight: 2200kg
Dimension(L*w*h): 2300×3300×2500 mm
$4000.00
Description

Hydraulic Diesel 500L Concrete Mixer for sale


Brief Introduction
JZC-500 mobile hydraulic diesel concrete mixer is a self-falling concrete mixer which is a double-cone type mixing drum forward mixing and reverse discharging. It can mix plastic and semi-dry concrete.The mixing drum of the machine is rotated by the ring gear. It has a hydraulic feeding systerm. It is the best mixer for various non-electric supply areas and construction sites where it is not convenient to pull power lines.
Applications
Applicable to general construction sites, roads, bridges, hydropower projects and small and medium concrete component factories.

Advantages
1.Can not only use diesel, but also work with electricity.
2.Can be easily disassembled and transported.
3.Hopper lifting way: Hydralic
4.Reliable transmission, low noise, low energy consumption, compact structure, stable operation, simple operation, good mixing quality and high productivity.





Technical

Model   JZC500
Discharging Capacity   500L
Loading Capacity   800L
Productivity   20-25m3/h
Maximum Size of Aggregate   60-80mm
Diesel Engine Power   15/18hp
Power of Water Pump   2.2-3kw
Hopper Lifting   By hydraulic system
Accuracy of Water Supply   Error≤2%
Max Trailing Speed   20 km/h
Tyre Size   7.00-16
Speed of Mixing Drum   13-15 RPM
Dimensions in Container (L×W×H)   2300×3300×2500 mm
Overall Weight   2200kg
