Truck Model |
ZZ3257N3247P1 |
||||
Truck Brand |
SINOTRUK –HOWO A7 |
||||
Driving Type |
Left Hand Driving |
||||
Dimension(Lx W xH)(unloaded)(mm) |
8665x 2496x3490 |
||||
Cargo body size (L*W*H, mm) |
5800x2300x1500 |
||||
Cargo body thickness(mm) |
bottom:8mm, side:4mm |
||||
Lift type of Carriage |
middle lifting |
||||
Approaching angle/Departure angle(°) |
20/29 |
||||
Overhang(front/rear) (mm) |
1540/1550 |
||||
Wheel base (mm) |
3225+1350 |
||||
Max speed(km/h) |
78 |
||||
Curb weight(kg) |
11950 |
||||
Loading Weight(kg) |
25000 |
||||
Fuel tanker capacity(L) |
300 |
||||
Fuel consumption(L/km) |
20-30 L/100 km |
||||
Clutch |
Single-plate dry clutch Φ430mm |
||||
Engine Model (Steyr technology, made in China) |
Fuel Type |
Diesel |
|||
Engine Brand |
CNHTC |
||||
Horse Power, max(kw/rpm) |
380HP/ 371HP |
||||
Emission |
EURO 4, Euro 3, Euro 2 |
||||
Model |
D10.38-40 |
||||
Transmission |
Model |
HW19710, |
|||
Brake system |
Service brake |
Dual circuit compressed air brake |
|||
Parking brake |
spring energy, compressed air operating on rear wheels |
||||
Auxiliary brake |
Engine exhaust brake |
||||
Steering system |
Model |
hydraulic steering with power assistance Ratio:22.2—26.2 |
|||
Front axle |
HF9 disc brake, Steering with double T-cross section beam Loading capacity:9000kg |
||||
Rear axle |
AC16, Pressed axle housing, central double reduction with differential locks between axles and wheels Loading capacity:2x13000kg Ratio:5.45 |
||||
Color |
Optional(Waiting for picture to confirm) |
||||
Tire |
12.00R20 |
||||
Tire quantity |
12+1 Spare |
||||
Electrical system
|
Battery |
2X12V/180Ah |
|||
Alternator |
28V-1500kw |
||||
Starter |
7.5Kw/24V |
||||
Cab |
A7—W standard cab with air conditioner. 4 point full-floating air suspension, adjustable steering wheel with various heights and angles, air suspension seat,etc. |
